MSKMinimum-Shift Keying (When Shift/Bd = 0.5. It is impossible to get this ratio to be lower than 0.5, hence it is called the 'Minimum' shift.) Modulated signal with 2400Baud for traffic light control. Contains R09.16 telegrams as specified per VDV Standard 420.
