P25-CQPSK-CC_WF.png ‎(304 × 356 pixels, file size: 281 KB, MIME type: image/png)

Waterfall of P25 control channel in CQPSKContinuous Quadrature Phase-Shift Keying, from SDR#. Width is 15 kHzKiloHertz (kHz) 10^3 Hz.

File history

Click on a date/time to view the file as it appeared at that time.

Date/TimeDimensionsUserComment
current20:47, 21 August 2019304 × 356 (281 KB)Kj6psg (Talk | contribs)Waterfall of P25 control channel in CQPSK, from SDR#. Width is 15 kHz.
