Image of China Digital Radio taken from ZhengZhou, China. The digital sidebands which flank the FMFrequency Modulation signal are China Digital Radio signals. The image shows an example of China Digital Radio with spectrum occupancy mode C (300kHz stereo FMFrequency Modulation between two 50kHz digital signals).
