802.11ax waterfall focusing on a portion of a 40 Mhz wide WiFi 6 channel in the 2.4 Ghz band. Due to my SDR software's tuning ability, I cannot view the entire signal. I will try and get a better waterfall later.
The center spike is caused by my SDR's internal interference. Please disregard.
